| Type size and mechanical characteristic |
|
| NO. |
insulator |
rated
voltage
(KN) |
rated mechanical stretch comply (KN) |
connection mark (mm) |
structure altitude
(mm) |
Min.electric arc distance (mm) |
Min. nominal installation electric distance (mm) |
| 1 |
FXBW6-10/70 |
10 |
70 |
16 |
380 |
190 |
480 |
| 2 |
FXBW5-35/70 |
35 |
70 |
16 |
650 |
470 |
1280 |
| 3 |
FXBW5-35/100 |
35 |
100 |
16 |
670 |
450 |
1260 |
| 4 |
FXBW4-110/70 |
110 |
70 |
16 |
1240 |
1035 |
3180 |
| 5 |
FXBW4-110/100 |
110 |
100 |
16 |
1240 |
1015 |
3180 |
| 6 |
FXBW4-110/100 |
110 |
100 |
16 |
1240 |
1012 |
3050 | |
|
| Electric performance of insulator |
|
| NO. |
insulator |
rated
voltage |
thunderbolt full wave strike endurance voltage (peak) |
frequency endurance wet voltage (expiry value) |
| 1 |
FXBW6-10/70 |
10 |
115 |
45 |
| 2 |
FXBW5-35/70 |
35 |
230 |
95 |
| 3 |
FXBW5-35/100 |
35 |
230 |
95 |
| 4 |
FXBW4-110/70 |
110 |
550 |
230 |
| 5 |
FXBW4-110/100 |
110 |
550 |
230 |
| 6 |
FXBW4-110/100 |
110 |
550 |
230 | |
|
